Ph conductivity meter

Name: Ph conductivity meter
Brand: WEE SCIENTIFICS
Price: 5000.0 INR
Availability: InStock

Price 5000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Ph conductivity meter Specification

Accuracy
0.01 pH; 1% FS Conductivity

Display Type
Digital LCD Display

Control Type
Keypad Control

Temperature Resistance
0C to 60C

Power Supply
Rechargeable/Adapter

Shape
Rectangular

Features
Simultaneous display of pH and Conductivity, Portable, Auto Calibration

Type
Ph Conductivity Meter

Dimension (L*W*H)
210 x 205 x 65 mm

Equipment Type
Digital Measuring Instrument

Equipment Materials
ABS Plastic Housing

Power
9V DC Adapter or Battery

Voltage
230V AC, 50Hz

Material
ABS Plastic & Electronic Components

Application
Industrial, Laboratory, Water Testing

Battery Backup
8-10 hours

Output Interface
RS232 (optional)

Electrode Type
Combined Glass Electrode & Conductivity Sensor

Protection Class
IP54

Resolution
0.01 pH; 0.01 mS/cm

Data Hold Function
Yes

pH Range
0.00 to 14.00 pH

Conductivity Range
0 to 200 mS/cm

Operating Temperature
5C to 45C

Calibration
Three Point Automatic

Weight
Approx. 400 g

Temperature Compensation
Automatic (ATC)

About Ph conductivity meter

A pH meter is an electronic instrument used to measure the pH value of a solution, which indicates how acidic or alkaline the solution is.

A pH meter consists mainly of:

Electrode (sensor) detects hydrogen ion concentration in the solution.
Meter/display unit converts the electrical signal into a pH reading.

The pH scale ranges from:

0 to 6 Acidic
7 Neutral
8 to 14 Alkaline (basic)

Precise Dual Measurement Performance

This meter combines advanced pH and conductivity sensors in a single, compact instrument, providing reliable readings for both parameters. With automatic temperature compensation and auto calibration, measurements remain accurate regardless of environmental fluctuations. Its high-resolution display and keypad control facilitate easy operation and fast analysis, making it ideal for critical testing applications.

Built for Versatile Applications

Engineered for durability with a robust ABS plastic housing and IP54 protection, the instrument is suited for use in laboratories, industrial sites, or water quality testing in the field. Its portable design, long battery life, and optional RS232 interface make it an excellent choice for professionals needing precise water analysis on the go or in benchtop settings.

FAQ's of Ph conductivity meter:

Q: How does the automatic temperature compensation (ATC) feature benefit the measurement accuracy?

A: The automatic temperature compensation (ATC) ensures that pH and conductivity readings remain accurate by adjusting values based on the current sample temperature, minimizing any errors due to temperature variations between 5C and 45C.

Q: What is the recommended process for calibrating this meter?

A: This meter supports three-point automatic calibration, allowing you to quickly and easily calibrate at multiple standard solutions. Simply follow the on-screen prompts and use calibration buffers to achieve precise calibration for reliable measurements.

Q: When should I use the data hold function?

A: The data hold function is helpful when you need to lock a measurement on the display, especially during fieldwork or when recording data manually. Activate it whenever you want to freeze the current reading for documentation purposes.

Q: Where can this pH conductivity meter be applied effectively?

A: It is designed for diverse applications such as industrial process monitoring, laboratory experiments, and water testing in both field and indoor environments, due to its portable build, robust design, and reliable measurement capabilities.

Q: What are the advantages of simultaneous display of pH and conductivity?

A: Simultaneous display allows users to monitor both pH and conductivity in real time without toggling between modes, saving time and reducing the risk of recording errors during multi-parameter analysis.

Q: How long does the battery backup last under regular usage?

A: The meter provides 8-10 hours of operation on a full battery charge, ensuring sustained performance during fieldwork or extended laboratory sessions before requiring recharge.
