Dip Coating Unit

Name: Dip Coating Unit
Brand: WEE SCIENTIFICS
Price: 115000.0 INR
Availability: InStock

Price 115000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Dip Coating Unit Specification

Heating Capacity
Optional Integrated Heater - Up to 120C

Shape
Rectangular, Benchtop

Features
Programmable Dipping Cycles, Variable Speed, Uniform Coating, Temperature Adjustable, Corrosion Resistant, Low Maintenance

Accuracy
1 mm/min

Power Supply
AC Mains

Display Type
Digital LCD Display

Speed Range
0.1 to 100 mm/min (Adjustable)

Control Type
Digital Microprocessor-Based Controller

Temperature Resistance
Up to 150C

Glass Type
All Standard Microscope Slides, Fiber Optic Rods

Type
Lab Model Dip Coating Unit

Dimension (L*W*H)
350 mm x 300 mm x 500 mm

Equipment Type
Automatic Dip Coating Machine

Equipment Materials
Stainless Steel Body, Anodized Aluminum Arm

Power
60 W

Voltage
220-240 V AC, 50/60 Hz

Material
Stainless Steel, High-Grade Plastic Components

Application
Thin Film Deposition, Glass/Fiber Coating, R&D Laboratories, Semiconductor Research

Capacity (Ltr)
Up to 5 Liters

Safety Features
Over-temperature & Over-current Protection, Emergency Stop Switch

Packing Type
Export Quality Wooden Case

Automation Level
Programmable, Semi-Automatic/Automatic

Sample Holder
Multi-Position Holder with Adjustable Grips

Noise Level
< 60 dB

Timer
Digital Timer - 0 to 9999 s

Carriage Type
Low Vibration Linear Motion

Dipping Stroke Length
Maximum 150 mm (customizable)

Weight
Approx. 14 kg

Coating Uniformity
2% across substrate

Operating Temperature Range
10 to 40C

Maintenance
Tool-less Access, Easy Clean Surfaces

Dip Coating Unit Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
5-10 Days

About Dip Coating Unit

Stroke Length (Max): 220 mm

Stroke Length Adjustment:

Continuously adjustable from 0

to 220 mm

Controller: 4.5-inch HMI Touch

Panel

Operation:

Adjustable dip speed

Adjustable dwell time

Adjustable withdrawal speed

Adjustable home position

Optional Features:

Magnetic stirrer

Ultrasonicator-assisted coating

UV-assisted coating

Reliable and Accurate Coating

This dip coating unit achieves precise, uniform coatings by utilizing a digital microprocessor controller and an accuracy of 1 mm/min, while maintaining low noise levels below 60 dB. Whether you require coatings on glass or fiber optical rods, this benchtop lab model delivers consistent results for research and industrial applications alike.

Safety, Convenience, and Maintenance

Designed with user safety in mind, the unit incorporates over-temperature and over-current protections alongside an emergency stop. All maintenance procedures are straightforward, thanks to tool-less access and easy-clean surfaces, reducing downtime and improving workflow efficiency in busy laboratory environments.

Advanced Features and Versatility

Suitable for thin film deposition, glass/fiber coating, and semiconductor research, this machine offers programmable dipping cycles, variable speed (0.1 to 100 mm/min), and optional integrated heating up to 120C. The stainless steel and anodized aluminum construction ensures durability and reliable performance even in demanding research settings.

FAQ's of Dip Coating Unit:

Q: How does the programmable automation benefit dip coating applications?

A: Programmable automation enables users to set custom dipping cycles, speeds, and durations, ensuring high reproducibility and uniformity across multiple samples. This streamlines workflow and minimizes manual intervention, making the process more efficient and reliable-especially valuable in research or high-throughput environments.

Q: What substrate types are compatible with this dip coating unit?

A: The equipment supports all standard microscope slides and fiber optic rods, making it versatile for coating various glass, fiber, or similarly sized substrates commonly used in research and development settings.

Q: When should I use the integrated heater option, and what is its capacity?

A: The integrated heater is ideal for applications requiring controlled substrate or solution temperature, such as enhancing adhesion or controlling evaporation rates. It can raise temperatures up to 120C, within the unit's overall resistance of up to 150C.

Q: Where is this dip coating unit best utilized?

A: It is best suited for R&D laboratories, semiconductor research facilities, and any environment requiring precision thin film deposition on small-scale substrates. Its compact benchtop design and low maintenance make it practical for laboratory use.

Q: What are the maintenance requirements for this dip coating machine?

A: Maintenance is minimal due to the tool-less access and easy-clean surfaces. Routine checks for cleanliness and component integrity are sufficient to ensure long-term, trouble-free operation.

Q: How does the machine ensure user safety during operation?

A: Several built-in safety features-like over-temperature and over-current protection, along with an emergency stop switch-protect both the user and the equipment from potential hazards. The system also operates quietly, creating a safer and more pleasant lab environment.

Q: What process controls and display features does the unit offer?

A: A digital microprocessor-based controller allows precise adjustment of dipping parameters, while a digital LCD display provides real-time feedback on the process, making operation intuitive and monitoring convenient.
