Electro Spinning Machine

Name: Electro Spinning Machine
Brand: WEE SCIENTIFICS
Price: 450000.0 INR
Availability: InStock

Price 450000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

Electro Spinning Machine Specification

Features
Integrated High Voltage Power Supply, Adjustable Flow Rate, Safety Interlocks, Emergency Stop Switch, Transparent Observation Window, Multi-Nozzle Compatibility

Temperature Resistance
Up to 120C

Heating Capacity
No inbuilt heating

Power Supply
AC Mains

Glass Type
Borosilicate Glass (solution containers)

Control Type
Digital with Touch Screen

Accuracy
1% (flow rate and voltage)

Display Type
LCD Digital Display

Shape
Rectangular

Speed Range
Collector: 100-3000 rpm

Type
Electro Spinning Machine, Electro Spinning Machine

Dimension (L*W*H)
550 mm x 450 mm x 350 mm

Equipment Type
Laboratory - Research Grade

Equipment Materials
Stainless Steel body with Acrylic Visor

Power
500 W

Voltage
220 V AC

Material
Metal & Glass (Chamber), Stainless Steel (Nozzle), Non-reactive Plastic (Holders)

Application
Nanofiber Fabrication, Research, Laboratory, Polymer Science

Capacity (Ltr)
1-2 ml/min (solution flow rate)

Working Distance
Adjustable 50-250 mm

Syringe Pump Compatibility
Standard and Micro Syringe Compatible

Nozzle Types
Single or Multi-Nozzle options available

Weight
Approx. 25 kg

Safety Features
Emergency Stop, High Voltage Interlock

High Voltage Output
Up to 30 kV DC adjustable

Collector Types
Drum, Plate, Rotating Collector

Software Interface
PC Compatible with Data Logging

Humidity Control
Optional

About Electro Spinning Machine

Desktop type, small size and affordable price;

Integrates multiple functions, professional laboratory type,

easy to use; With heating and dehumidification function, it can

meet the spinning requirements of most materials; The diameter

of nanofibers is controllable, ranging from 20 to 1000 nm; More than 100 types of spinnable materials; Single needle, multi-needle and

coaxial needle can be replaced; Various nanofiber collectors; CE & FCC certified. Product parameters: High voltage power supply: Output voltage: DC 0+30kV, output current I mA, input voltage AC220 10%. and monitoring of the operating status of each function

Versatile Nozzle and Collector Configurations

The Electro Spinning Machine supports single and multi-nozzle options to suit varying throughput needs. Operators can select from drum, plate, or rotating collectors to achieve specific fiber alignments and morphologies. This adaptability is ideal for both exploratory research and small-scale production.

Advanced Digital Controls and Data Logging

Monitor and adjust every critical process parameter with the digital touchscreen interface. The system is PC compatible, enabling direct data logging for precise documentation and analysis. Adjustable flow rates and voltages (up to 30 kV DC) offer fine-tuned control over nanofiber creation.

Enhanced Safety and Observation Features

Safety is ensured with high voltage interlocks, an emergency stop, and a transparent acrylic visor. The stainless steel chamber is designed for chemical resistance, while all solution containers are made from temperature-resistant borosilicate glass, ensuring safe operation and easy process observation.

FAQ's of Electro Spinning Machine:

Q: How does the adjustable working distance benefit the electrospinning process?

A: The adjustable working distance (50-250 mm) allows precise control over fiber formation and deposition, helping tailor nanofiber characteristics for specific research or industrial applications.

Q: What types of syringes are compatible with this Electro Spinning Machine?

A: The machine is compatible with both standard and micro syringes, allowing researchers to work with a wide range of solution volumes and flow rates for various nanofiber fabrication needs.

Q: When should I opt for the multi-nozzle configuration?

A: Choose the multi-nozzle option when you need higher throughput or wish to simultaneously create multiple nanofiber mats, making the process more efficient for larger-scale research or prototyping.

Q: Where can this machine be installed safely in a laboratory?

A: Due to its safety features, compact design (550 x 450 x 350 mm), and robust stainless steel body, the machine fits most laboratory benchtops and should be installed in well-ventilated areas with access to a 220V AC mains supply.

Q: What is the process for adjusting the collector speed and flow rate?

A: Collector speeds (100-3000 rpm) and solution flow rates (1-2 ml/min) can be precisely adjusted through the digital touch screen, ensuring consistent nanofiber quality with 1% accuracy for both parameters.

Q: How does the optional humidity control feature impact nanofiber fabrication?

A: Humidity control, when included, stabilizes the spinning environment, minimizing unwanted variability in fiber formation due to ambient moisture changes. This is especially beneficial for reproducible scientific research.

Q: What are the main benefits of using this Electro Spinning Machine for nanofiber fabrication?

A: Key advantages include customizable process parameters, high safety standards, multi-nozzle and collector compatibility, integrated data logging, and transparent observation-all essential for reliable, research-grade nanofiber production.
