Fume hood

Name: Fume hood
Brand: WEE SCIENTIFICS
Price: 385000.0 INR
Availability: InStock

Price 385000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Fume hood Specification

Features
Chemical resistant body, low noise blower, fluorescent lighting, and electrical sockets

Glass Type
Toughened Glass Sash

Display Type
Analog Flow Meter

Shape
Rectangular

Control Type
Manual / Automatic Sash Option

Speed Range
Variable Sash Opening

Power Supply
Single Phase, 50 Hz

Temperature Resistance
Up to 120C

Type
Ducted Fume Hood

Dimension (L*W*H)
1200 x 800 x 2300 mm

Equipment Type
Laboratory Fume Hood

Equipment Materials
Powder Coated Mild Steel / GI Sheet

Power
2200 W

Voltage
220 V

Material
Mild Steel, GI and Glass Combination

Application
Chemical laboratories, research labs, pharma companies

Front Sash
Counterbalance Weighted

Exhaust System
Centrifugal Blower Included

Lighting
Fluorescent Lamp 1 x 40 W

Color
Light Grey/Blue

Service Fittings
Available for Gas, Water, and Air

Sink & Tap
Polypropylene Sink with Water Tap

Gas and Vacuum Valves
Yes

Mobility
Fixed Type

Base Cabinet
Provided with Storage Cabinet

Internal Lining
Chemical-resistant lining

Optional Accessories
Carbon Filter, UV Lamp, Extra Power Sockets

Sash Movement
Vertical Sliding

Construction
Double Walled

Noise Level
< 65 dB

Worktop Material
Granite or Epoxy Resin

Baffle System
Aerodynamic Design for Smooth Airflow

Airflow Type
Horizontal/Vertical Flow

Maximum Face Velocity
0.4 - 0.7 m/s

Fume hood Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
5-7 Days

About Fume hood

Working Area : 1500 x 2350 x 850mm (L x H x W)

o Constructions: Cabinets is made of SS Sheet 304 Grade 1.2

mm mat.

o Interiors coated with fire proof epoxy paint.

o Working table is covered with 20 mm polished Granite.

o Door: Front door is made of 6mm clear Toughened glass.

o Counter weight balance Front Door.

o Vertical sliding facility & the front door can be stopped at any

point.

o Exhaust System: Exhaust blower consists of single phase

motor which is enclosed in a PVC casing connected with a

PVC Exhaust Ducting.

o Blower Details: POWER -70/60 W

o CFM -600 CFM

o AIR VOLUME -850 / 700 M3 PER HOUR STATIC PRESSURE -

350 / 280 Pa

o SOUND LEVEL -50 / 45 dB

o INLET & OUTLET SIZE -8" (200 mm) RPM = 2400 / 2500 RPM

o Electrical panel: main on off switch

o Illumination on off switch

o 15 amps Socket with on off switch Motor on/off switch

o Ducting: M.O.C 3 mm PVC Quantity 5 feet

Superior Construction and Chemical Resistance

Designed with a double-walled body using powder-coated mild steel or GI sheet, this fume hood ensures long-term durability. The internal lining and worktop-offered in granite or epoxy resin-are highly chemical resistant, protecting users and equipment from harsh reagents. The structure can endure temperatures up to 120C, making it ideal for a wide range of laboratory applications.

Efficient Airflow and Quiet Operation

Featuring an aerodynamic baffle system and included centrifugal blower, this fume hood achieves smooth airflow and effective contaminant removal. Face velocities range from 0.4 to 0.7 m/s, and noise levels remain below 65 dB, creating a comfortable workspace. Variable sash operation and a manual or automatic sash option add convenience and energy efficiency.

Easy Operation and Enhanced Safety

The vertical sliding, counterbalance sash is made from toughened glass to provide visibility and protection. Integrated service fittings for gas, water, and air, as well as a polypropylene sink with tap, support a variety of laboratory processes. The built-in storage cabinet and optional accessories-such as a carbon filter, UV lamp, and additional sockets-further promote safety and organization.

FAQ's of Fume hood:

Q: How does the fume hood's airflow system operate and what types are available?

A: The fume hood is equipped with either horizontal or vertical airflow, using an aerodynamic baffle system to ensure smooth and effective removal of hazardous fumes. The included centrifugal blower maintains variable face velocities between 0.4 - 0.7 m/s, supporting a clean and safe laboratory environment.

Q: What materials are used for the worktop and why are they beneficial?

A: You can choose between granite or epoxy resin worktops, both offering strong chemical resistance and high durability. These materials are ideal for laboratories conducting frequent chemical handling, as they protect against spills, scratches, and moderate heat exposure up to 120C.

Q: When should I use the manual versus automatic sash control option?

A: Manual sash controls are suited for general daily use and provide direct control over sash position, while automatic options are recommended for laboratories aiming to optimize energy efficiency and enhance operator safety, especially in high-volume or multi-user settings.

Q: Where can this fume hood be installed and what applications does it support?

A: This ducted fume hood is designed for installation in chemical laboratories, research institutions, and pharmaceutical companies. Its robust build and chemical-resistant features make it suitable for processes involving hazardous substances, ensuring user safety across diverse scientific fields.

Q: What is the procedure for routine maintenance and cleaning?

A: Routine maintenance involves regularly inspecting the airflow (using the analog flow meter), cleaning the worktop with suitable solvents, checking the chemical-resistant linings, and ensuring the centrifugal blower and lighting function properly. It is also important to periodically clean or replace optional carbon filters and check service fittings and valves for proper operation.

Q: How does the built-in storage and accessory options enhance user experience?

A: The integrated base storage cabinet allows safe and convenient storage of chemicals and lab tools, while optional accessories such as the UV lamp, carbon filter, and additional power sockets expand the utility and safety of the workstation, adapting the hood for varied experimental needs.
